PHMTOOLS provides topkit tower crane, luffing tower crane, flat top tower crane.
The jib material is low-alloy high-strength steel, which can be used for 60m, 55m, 50m, 45m, 40m, 35m, and 30m.

The hoisting mechanism has two control methods: ordinary three-speed and frequency conversion speed regulation.
The driver's cab is independent and external, with good vision, large internal space, comfortable and safe operation.

TOPKIT TOWER CRANE

TOPKIT TOWER CRANE
Model		QTZ40(TC4208)	QTZ40(TC4708)	QTZ40(TC4808)	QTZ40(TC4810)	QTZ50(TC5008)	QTZ50(TC5010)
Rated Load Moment	KN.m	400	400	400	400	500	570
The Max Lifting Capacity	t	4	4	4	4	4	4/5
The Max Working Scope	m	42	46.8	48	48	50	50
The Max Scope Rated Lifting Capacity	t	0.8	0.8	0.7	1.0	0.8	1.0
Setting Height	m	30/100	30/100	30/100	30/100	30/120 35/120	30/120 35/120
Lifting Speed	m/min	(a=2)59/27/6 (a=4)30/12.3/3	(a=2)59/27/6 (a=4)30/12.3/3	(a=2)59/27/6 (a=4)30/12.3/3	(a=2)59/27/6 (a=4)30/12.3/3	(a=2)62/30/9 (a=4)30/12.3/3	(a=2)62/30/9 (a=4)30/12.3/3
Derricking Speed	m/min	38/26	38/26	38/26	38/26	38/26	38/26
Slewing Speed	r/min	0-0.62	0-0.62	0-0.62	0-0.62	0-0.62	0-0.62
Climbing Speed	m/min	0.4	0.4	0.4	0.4	0.4	0.4
Total Motor Power	kw	25.12	25.12	25.12	25.12	25.12	25.12/28.12
Working Temperature	℃	-20~+40
Working Voltage	V	380±5%
The Max Working Wind Pressure	N/㎡	250
